Fowler, 0.8mm Girod “Horizontal” Test Indicator, 52-563-252-0
SKU
525632520
Special Price
$177.28
$226.70
- You Save: $49 (21.80%)
The ultimate in Swiss workmanship, Fowler-Girod Indicators are internationally respected as "The Best."
All Fowler-Girod Indicators meet or exceed Federal Specifications for accuracy. Their exceptional design and quality assures you a lifetime of accuracy and total reliability.
Features:
• Monobloc body design has 7 fine jeweled bearings isolated in a shock-proof assembly
separate from the outer body and cannot be influenced by external pressures.
• Independent, interchangeable movement transmits measuring value via rack & pinion.
• Rugged anti-magnetic one-piece housing is satin-chrome plated to resist corrosion.
• Auto-reverse mechanism with adjustable ball bearings, provides ultra-smooth action.
• Carbide contact points (1⁄2" length) can swivel over 210° to reach any location.
• Universal mounting: dovetails supplied at top, front and back for proper set-up.
• Adjustable bezel and dial easily set and reset to zero. Microfine graduations on dials. Your choice of dial diameters.
• Replacement points: .040" No. 52-567-101; .080" No. 52-567-102-0 and .120" No. 52-567-103-0.
• Replacement dovetail clamping stems: 7⁄32" diameter No. 52-565-091 and 1⁄4" diameter
No. 52-565-092.
• Price includes indicator, fitted case, carbide contact points (see chart), and two dovetail clamping stems: 7⁄32" and 1⁄4" diameter.
*Image shown for representational purposes only
All Fowler-Girod Indicators meet or exceed Federal Specifications for accuracy. Their exceptional design and quality assures you a lifetime of accuracy and total reliability.
Features:
• Monobloc body design has 7 fine jeweled bearings isolated in a shock-proof assembly
separate from the outer body and cannot be influenced by external pressures.
• Independent, interchangeable movement transmits measuring value via rack & pinion.
• Rugged anti-magnetic one-piece housing is satin-chrome plated to resist corrosion.
• Auto-reverse mechanism with adjustable ball bearings, provides ultra-smooth action.
• Carbide contact points (1⁄2" length) can swivel over 210° to reach any location.
• Universal mounting: dovetails supplied at top, front and back for proper set-up.
• Adjustable bezel and dial easily set and reset to zero. Microfine graduations on dials. Your choice of dial diameters.
• Replacement points: .040" No. 52-567-101; .080" No. 52-567-102-0 and .120" No. 52-567-103-0.
• Replacement dovetail clamping stems: 7⁄32" diameter No. 52-565-091 and 1⁄4" diameter
No. 52-565-092.
• Price includes indicator, fitted case, carbide contact points (see chart), and two dovetail clamping stems: 7⁄32" and 1⁄4" diameter.
*Image shown for representational purposes only
